Transactions of Nanjing University of Aeronautics & Astronautics
Dynamic Constitutive Model of Physical Simulation in High-Speed Blanking for C5191 Phosphor Bronze
- Article
- Figures
- Metrics
- Preview PDF
- Reference
- Related
- Cited by
- Materials
Abstract:
Strain hardening, strain rate strengthening and thermal softening data of C5191 phosphor bronze at high-speed blanking are not easy to be obtained with a general measure method, therefore, it is quite difficult to establish the dynamic constitutive model. To solve this problem, the tensile properties at a strain rate of 1 s-1 by GLEEBLE-3500, and dynamic tensile conditions at strain rates of 500, 1 000 and 1 500 s-1 by split Hopkinson tensile bar (SHTB) apparatus are studied. According to these test data, the classic Johnson-Cook equation is modified. Furthermore, the modified Johnson-Cook equation is validated in the physical simulation model of high-speed blanking. The results show that the strength of C5191 phosphor bronze maintains a certain degree of increase as the strain rate increasing and presents a clear sensitivity to strain rate. The modified Johnson-Cook equation, which has better description accuracy than the classical Johnson-Cook equation, can provide important material parameters for physical simulation models of its high-speed blanking process.
Keywords:
Project Supported:
Clc Number:
TG386
