Abstract:

The icing of unmanned aerial vehicles （UAVs） poses a serious threat to flight safety. The available energy of UAVs is inadequate， so an energy-efficient ice protection strategy is required. In this paper，an integral fiberglass composite airfoil is tested， which has super-hydrophobic coating and embedded electro-thermal film （SHS-EET）. The proportional integral derivative method （PID） is used to adjust surface temperature and heating power. Experiments are conducted in an icing wind tunnel to verify the anti-icing/de-icing performance of the strategy. The results show that the super-hydrophobic coating without a heating source fails to avoid the formation of accreted ice. In addition， the ice shedding period of SHS-EET is reduced by 64.6% and the energy consumption is reduced by 72.3%. As the surface temperature is lower than 10 ℃， SHS-EET achieves dry anti-icing. And it reduces energy consumption by 27.5% compared with the wet anti-icing strategy of a fiberglass airfoil with underground electro-thermal film （FG-UET）. The hybrid anti-icing /de-icing strategy is beneficial for the development of the icing protection system for UAVs.

Keywords:

Project Supported:

This work was financially supported by the National Natural Science Foundation of China （Nos. 11832012， 12227802）.

Clc Number:

V19
